Imperial IHPA-6-36-NG 36" Hot Plates, 6 Burners, Natural Gas

PyroCentric™ Burner heads are standard
- Two rings of flame for even cooking no matter the pan size,
- PyroCentric 32,000 BTU (9 KW) anti-clogging burner with a 7,000 BTU/hr. (2 KW) low simmer feature

Optional burner heads
- Optional, interchangeable Saute and Wok Jet burner heads

Lift-off front grates
- 12" x 13" (305 x 330 mm) size
- Heavy-duty cast iron construction
- Anti-clogging pilot hood shields pilot from grease and debris
- Grate actually provides the shield
- Pots slide easily from section to section

Lift-off back grates
- 12" x 13" (305 x 330 mm) size back grate
- Sized for positioning large stock pots directly over burner
- Hot air dam deflects heat onto the stock pot
- Protects backguard from direct flame discoloration

Exterior features
- Range match profile when placed on a refrigerated base or equipment stand
- Stainless steel front, sides and ledge
- Welded stainless steel seams
- Large 5" (127 mm) stainless steel landing ledge
- Control knobs are durable cast aluminum with a Valox™ heat protection grip
- Full width crumb tray
- 4" (102 mm) heavy duty legs with adjustable feet
- One year parts and labor warranty

Specifications

SPECIFICATIONS
Model number	IHPA-6-36
Power type	Natural or LP gas
Manifold pressure	Natural gas: 5.0, LPG: 10.0
Total BTU/hr.	192,000 (56 KW)
Installation type	Counter top model
OPEN BURNER SPECS
Open burner output	32,000 BTU (9 KW)
Low simmer output	7,000 BTU (2 KW)
Burner style	PyroCentric, dual flame
Burner material	Cast iron
Number of burners	6 open burners
Removable	Yes
Ignition type	Pilot
Grate style	Anti-clogging, shield design
Grate material	Cast iron
Front grate size	12" x 11" (305 x 279 mm)
Back grate size	12" x 13" (305 x 330 mm)
Gaskets/screws	No
EXTERIOR SPECS
Wrap material	Stainless steel exterior, except back
Control knobs	Aluminum with Valox™ heat protecting grip
Dimensions	36" w x 31-3/8" d x 10-3/4" h (914 x 797 x 273 mm)
Legs	4" (102 mm) stainless steel, adjustable feet
Crated dimensions	38-1/2" w x 34" d x 12" h (978 x 864 x 304 mm)
Ship weight	210 Lbs. (95 Kg)
CERTIFICATIONS
Listings

Documents

• Specification Sheet
• Owner Manual
