Hoshizaki C-80BAJ Cubelet Icemaker, Air-cooled, Built in Storage Bin

Product Features

• Dimensions: 14-7/8″ W x 22-5/8″ D x 33-1/2″ H
• Up to 80 lbs of ice produced per 24 hours
• Up to 22 lbs of built-in storage capacity
• Produces mini cubelet nugget-style ice
• Undercounter design is less than 34″ tall
• Front in and front out airflow
• UL approved for outdoor use
• Swing style field reversable door
• Accessory – HS-5061 drain pump assembly
• R-134a refrigerant (3.92 oz. / 111 g)
• Heat Rejection:1850 BTU/hr
• Ambient temperature range: 45 – 100°F
• Water temperature range: 45 – 90°F
• Water pressure: 7 – 113psig
• Voltage range: 104 – 127V
• 4 amps (15 Amp Max fuse)
• 17.3 kwh/100 lbs.@ 90/70
• Single phase, 115v/60/1, 6 ft cord with NEMA 5-15 plug
• Clean ice and easy maintenance lead to longer unit life span
• Two Years: Parts & Labor warranty on entire machine.
• One Year: Parts & Labor warranty on optional HS-5061 Drain Pump Assembly.

This compact undercounter Cubelet Icemaker is the perfect addition to any hotel suite, office breakroom, or kitchen. The C-80BAJ is capable of producing approximately 80 lbs of Cubelet style ice cubes per day, and the built-in storage bin will hold up to 22 lbs* of ice at a time. The Undercounter design is less than 34″ tall. The Air-cooled design also features a Front in and front out airflow system that eliminates the need for side and rear clearance. Perfect for fitting into tight spaces. UL approved for outdoor use. Drain pump not included. Replaces C-101BAH.

Specifications

Documents

• Product Spec Sheet
